Overview

Example cases are compact, mid-level demos that deepen your skills beyond step-by-step tutorials. Each case presents a simulation setup with sparser instructions, aimed at users who already have a basic grasp of the Allsolve workflow.

Acoustics

Acoustics 001 - Loudspeaker in a cabinet

Multiphysics loudspeaker model with acoustic waves, solid mechanics, and a PML boundary

SAW 001 - Unit cell

Piezoelectric surface acoustic wave unit cell with anisotropic materials and periodic boundaries

CHT

CHT 000 - Governing equations

Theory reference: Navier-Stokes, advection-diffusion, and heat diffusion equations behind CHT

CHT 001 - Manifold microchannel heat sink

Conjugate heat transfer in a microchannel heat sink with temperature-dependent viscosity

CHT 002 - 2D Taylor-Couette flow

Conjugate heat transfer between rotating concentric cylinders with analytical verification

Electric motors

EM 001 – PMSM 2D torque analysis

2D permanent magnet synchronous motor with torque sweep and reference comparison

EM 002 – IM 2D torque analysis

2D induction motor transient simulation validated against TEAM Problem 30

Harmonic balance

HB 001 - AC Joule heating

Multiharmonic Joule heating in an aluminium wire with frequency sweep

HB 002 - Backbone curve of a clamped-clamped beam

Nonlinear resonance backbone curve using multiharmonic continuation

HB 003 - MEMS Microspeaker

Multiphysics microspeaker with electrostatics, fluid, and harmonic distortion analysis

MEMS

MEMS 000 - Importing .gds files & mesh extrusion

GDS file import with layer stackup and extruded mesh generation

MEMS 001 - Combdrive eigenmodes

Eigenmode analysis of a MEMS combdrive accelerometer from a GDS layout

MEMS 002 - Combdrive static deflection

Electrostatic actuation and voltage sweep on a MEMS combdrive

MEMS 003 - Viscoelasticity benchmark

Transient viscoelastic rod benchmark with Prony series and analytical comparison

MUTs

MUTs 001 - PMUT array

6x6 PMUT array with piezoelectricity, acoustic waves, and PML absorbing layers

MUTs 002 - Piezocomposite transducer

1-3 piezocomposite transducer element with transient wavelet excitation

Packaging

Packaging 001 - FCBGA free warpage

Free warpage and thermal stress in an FCBGA package with temperature-dependent materials

Radio frequency

RF 000 - Equations for electromagnetic waves

Theory reference: wave equation derivation from Maxwell's equations for the FEM solver

RF 001 - Eigenmode ports and S-parameters

Microstrip line with eigenmode port excitation and S-parameter extraction

RF 002 - Lumped ports and RLC components

Grounded coplanar waveguide with a lumped resistor port and impedance sweep

RF 003 - Patch antenna

Patch antenna with airbox PML, S-parameters, and radiation pattern extraction

Superconductors

SC 003 - Quench

Multiphysics quench simulation in a YBCO tape with temperature-dependent critical current
